Description
General Specifications
Supported Cameras: VPort 36-1MP Series, VPort 56-2MP Series
Communication Protocols: RS-485 (2400 to 38400 bps), Pelco-D/ Pelco-P
Photocell: Optional Sensitivity Adjustable Photocell for IR on/off and camera ICR switch
Power Requirements
Power Source: 24 VAC (±10%), 24 VDC (±10%)
Power Consumption: 25 W, maximum 40 W
Physical Characteristics
Housing Material: Aluminum die-casting
Dimensions: 219 x 510 x 530 mm (8.62 x 20.08 x 20.87 in)
Unit Weight: 11 kg
Max. Load Weight: 7 kg
PAN/TILT/ZOOM
Pan Range & Speed: 0 to 360° (endless), 0.025 to 120°/s
Tilt Range & Speed: -90 to 40° (endless), 0.025 to 40°/s
Preset Accuracy/Repeatability: Max. ±0.1° / Max. ±0.05°
Preset Speed: Max. 120°/s (Pan), Max. 40°/s (Tilt)
Environmental Limits
Operating Temperature: -40 to 70°C (-40 to 158°F)
Storage Temperature: -50 to 80°C (-58 to 176°F)
Ambient Relative Humidity: up to 90% RH
IP Rating: IP66
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
