Raven-640-Analog 17µm: Security solutions with SWaP infrared cameras

Raven-640-Analog 17µm: SWaP thermal infrared camera
The Raven-640-Analog 17µm is a longwave infrared imaging camera, specially designed for the demanding security market with a high operating temperature range. The thermal image is crisp and clear, even under difficult weather conditions and in complete darkness without the use of additional illumination.

To meet the needs of the professional security community the Raven-640-Analog 17µm can be configured with various lenses for short-range, medium-range and long-range observation. The camera interface can be PAL/NTSC video for a regular CCTV security network. The camera is controlled by RS232. The integration and use of these infrared security cameras are so easy, that no operator training is required.

The detector of the Raven-640-Analog 17µm has a very high resolution of 640 x 480 pixels and offers the earliest and most reliable detection of even the smallest temperature change and the smallest object. The on-board image processing guarantees excellent image quality without the need for adjustment.



Key Benefits

Accessories
  • Shutter manager
  • On-board image processing
  • Small pitch for longer DRI values
  • One mount for exchangeable lenses
  • Small Size, low Weight and low Power consumption (SWaP)

Raven-640-Analog 17µm: Detailed specifications





Array Specifications

Raven-640-Analog 17µm
Array type Uncooled microbolometer (a-Si)
Spectral band 8 µm to 14 µm
# Pixels 640 x 480
Pixel pitch 17 µm
Pixel operability > 99 %
Array Cooling Uncooled





Camera Specifications

Raven-640-Analog 17µm
Lens (Included)
Focal length 18 mm f/1, HFOV 33.6°, standard manual focus
Optical interface Lens mount supports multiple lenses
Imaging Performance
Frame rate Max. 30Hz NTSC
Shutter Yes
Integration type Rolling shutter
A to D conversion resolution 16 bit
Interfaces
Camera control RS232 (XSP)
Analog output PAL or NTSC
Power Requirements
Power consumption 2.6 W
Power supply 12 V
Physical Characteristics
Shock 70 G, 2 ms halfsine profile (without shutter)
Vibration  4.5 G (5Hz to 500Hz)
Ambient operating temperature -40°C – 60°C
Dimensions 49W x 49H x 67L mm³ (lens not included)
Weight camera head 200 g (lens not included)





 Software Specifications: Xeneth Basic
With Xeneth Basic you can:

  • Control all the infrared camera control settings
  • See a live image view
  • Save images





Category:

Description

Best Detection, Recognition and Identification values to protect your facilities.

The Raven-640-Analog 17µm is an infrared imaging camera, specially designed for the demanding security market with a high operating temperature range. The thermal image is crisp and clear even under difficult weather conditions and in complete darkness without the use of additional illumination. To meet the needs of the professional security community the Raven-640-Analog 17µm can be configured with no less than 12 different lenses, making it possible to adapt the camera to a wide variety of security applications.
