CP-102E 2-port RS-232 PCI Express x1 serial board

Highlights

PCI Express x1 compliant
921.6 Kbps maximum baudrate for super fast data transmission
128-byte FIFO and on-chip H/W, S/W flow control
Low profile form factor fits small-sized PCs Drivers provided for Windows (2000, XP/2003/Vista/2008 x86/x64), Linux 2.4, Linux 2.6 (x86/x64) QNX 6, Windows XP Embedded, SCO OpenServer 5/6, UnixWare 7
15 KV ESD protection on the board

Description

Includes

1 x CP-102E/EL unit
1 x support CD/DVD
1 x installation guide
1 x warranty statement

Specs:

Comm. Controller
16C550C compatible

Bus
PCI Express x1

Connector
CP-102E DB9 maleCP-102EL DB25 female

Number of Ports
2

Serial Standards
RS-232

ESD Protection
15 KV on the board

Operating Systems
Windows (2000, XP/2003/Vista/2008 x86/x64), Linux 2.4, Linux 2.6 (x86/x64), QNX 6, Windows XP Embedded, SCO OpenServer 5/6, UnixWare 7

Dimensions
CP-102E 85.04 x 100 mm (3.40 x 4.00 in) CP-102EL 67.21 x 101.97 mm (2.69 x 4.08 in)

Operating Temperature
0 to 55°C (32 to 131°F)

Overview:

The CP-102E and low profile CP-102EL are 2-port PCI Express boards designed for POS and ATM applications. Moxa’s PCI Express boards are a top choice of industrial automation engineers and system integrators, particularly since the boards support many different operating systems, including Windows and Linux.

The CP-102E/EL’s 2 RS-232 serial ports support a super fast 921.6 Kbps baudrate, and provide full modem control signals to ensure compatibility with a wide range of serial peripherals. In addition, the boards’ x1 classification allows them to be installed in any PCI Express slot.
