Description
• Device
Device Type Video Decoder
Number of Channels 1
• Video
Decompression MPEG-4 SP, MPEG-4 ASP
Maximum Frame Rate vs.
Resolution 30 fps at 720 x 480 (Full D1, NTSC); 25 fps at 720 x 576 (Full D1, PAL)
• Audio
Compression 8 kHz, Mono, PCM, 16 bit encoding
Audio-In 3.5 mm Phone Jack
Audio-Out 3.5 mm Phone Jack
• Network
Protocol & Service TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP,
UPnP, SNMP, Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IP address filtering; HTTPS encryption; Password protected user levels
• Interface
Analog Video Output 2, CVBS, 1.0Vp-p with 75 Ω loading BNC connector; Y/C, 0.286Vp-p with 75 Ω loading S-video connector
Serial Port RS-485, RS-422, RS-232, terminal block
• General
Power Source /
Consumption DC 12V ±10% / 3.8 W
Weight 350 g (0.77 lb)
Dimensions (W x H x D) 112 mm x 37.2 mm x 119 mm (4.41″ x 1.46″ x 4.68″)
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Operating Humidity 10% ~ 85% RH
Approvals Video Decoder: CE, FCC; Adapter: CE, TUV-GS, UL, RCM, CCC
• Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available
